Description
Pinnacle is the most compact of stair lifts, folding closer to the wall so others can pass easily. Harmar’s exclusive automatic and mechanical folding rail removes obstructions and trip hazards at the lower landing area. Its operation is automatic, the user does not need to stop or have someone else assist. And since it’s mechanical, there are no additional switches or controls.
Features
- The over-sized worm gear offers greater stability
- Lubrication free, keeps you, your stairs and even your pets free from a mess
- Symmetrical design provides industry’s most compact folded width
- Swivel seat at upper landing, for easy and safe, entry and exit away from staircase
- Operable in a power outage – up to 40 trips!
- Safety sensors in the footrest and optional in the chassis will stop the lift if it meets an obstruction
Specifications
-
Weight Capacity – 300 lb (136 kg)
-
Seat Size Seat – 19″ W x 16″ D
-
Back – 16.5 W x 9.5″ H
-
Speed – 20 FPM
-
Folded Width – 11″
-
Track Length – 15’6″ Standard Up to 32′
-
Power – 24V DC
-
Incline Limits – 32° – 45°
-
Outdoor – No
-
Drive System – Nylon Polymer Helical Worm Gear
-
Safety Features – • Centrifugal Overspeed Brake • Bi-directional Footrest with Obstruction Sensor • Swivel Seat Cutt-off Switch • Final Limits • Chassis Obstruction Sensors
-
Warranty2-Year Parts Warranty
10-Year on Gear Rack
1-Year on Battery -
Optional• Folding Rail
• Retractable Seat Belt
• Key Lock
• Extra Rail
